| General | |
| Frequency Range | 136-174MHz (V) , 400-480MHz (U) |
| Channel Capacity | 4000 channels |
| Channel Spacing | 25KHz (Wide Band) 12.5KHz (Narrow Band) |
| Phase-locked Step | 5KHz, 6.25KHz |
| Operating Voltage | 7.4V DC ±20% (2100mAh) |
| Frequency Stability | ±2.0ppm |
| Operating Temperature | -20℃~ +55℃ |
| Size | 129×61×39mm (with battery pack) |
| Weight | 282g (with battery pack, antenna) |
| Transmitting Part | |
| Power Output | VHF: 7/5/2.5/1W, UHF: 6/5/2.5/1W |
| Modulation limit | ±5.0KHz@25KHz (Wide Band) ±2.5KHz@12.5KHz (Narrow Band) |
| Adjacent Channel Power | ≥70dB (Wide Band) ≥60dB (Narrow Band) |
| Hum & Noise | ≥40dB (Wide Band) ≥36dB (Narrow Band) |
| Spurious Emission | ≤-36dB (Wide Band) ≤-36dB (Narrow Band) |
| 4FSK Digital Modulation | 12.5KHz（data）7K60FXD 12.5KHz（data+voice）7K60FXE |
| Audio Distortion | ≤5% |
| Error rate | ≤3% |
| Receiving Part | |
| Sensitivity (12dB SINAD) | ≤0.25μV (Wide Band) ≤0.35μV (Narrow Band) |
| Digital Sensitivity | 0.3uV/-117.4dBm (BER 5%) 0.7uV/-110dBm (BER 1%) |
| Adjacent Channel Selectivity | ≥70dB (Wide Band) ≥60dB (Narrow Band) |
| Spurious Emission | ≤-57dB (Wide Band) ≤-57dB (Narrow Band) |
| Spurious Rejection | ≥70dB (Wide Band) ≥70dB (Narrow Band) |
| Blocking | 84db |
| Hum & Noise | ≥45dB (Wide Band) ≥40dB (Narrow Band) |
| Audio Distortion | ≤5% |
| Audio Power Output | 1000mW/16Ω |
